Description of CYCJET High Dpi Inkjet Printer / Inkjet Qrcode Printer ALT502UV
ALT502UV is a "piezo inkjet" printer (PIJ). This technology combines the advantages of UV inkjet printer and industrial inkjet printing system. It can print graphics, text, and GS1-128 compliant barcodes without the need to stick labels on the boxes.
Compared with label technology, the use of PIJ inkjet printers can reduce the overall cost and reduce waste. This will help improve overall operational efficiency and help manufacturers achieve sustainable development goals. Coupled with CYCJET's self-developed non-hazardous vegetable oil-based ink, manufacturers can not only obtain high-quality labels but also greatly reduce the negative impact on the environment.
When designing and producing the ALT502UV inkjet printer, we work hard to keep the qualities of our classic goods that have helped so many customers in addition to introducing enhancements that outperform those of our rivals.
Without having to stop this inkjet printing machine, the large-capacity ink tank could lower the frequency of ink replacement in high-speed production. Large-format printing layouts of CYCJET high-resolution inkjet printer may be produced using multiple nozzles supplied by a single ink unit, and the ALT502UV controller also makes it possible to code boxes on several sides.
Technical Parameter of CYCJET High-resolution Inkjet Printer:
| Resolution |
Max 600X2200DPI
|
| Printing lines |
unlimited number of lines (maximum nozzle height range, arbitrary layout)
|
| Printing speed |
0-130m/min (different resolution, different speed)
|
| Printing contents |
variable and fixed text, pictures, PDF, barcode, QR code, DM code, database, etc.
|
| Printing fonts |
Windows operating system fonts
|
| Print heads |
one print head 54mm printing height
|
| Transmission |
Gigabit network
|
| External interface |
network interface, USB, RS232
|
| Printing direction |
downward printing or side printing
|
| Printing method |
single or continuous printing
|
| Ink type |
Oil-based ink, water-based ink, UV ink
|
| Ink color |
black, white, red, blue, invisible ink, etc.
|
| Nozzle cleaning |
one-key automatic cleaning
|
| Power requirements |
AC220V/50HZ
|
| Machine power |
300W
|
| Packing size |
85X55X55cm
|
| Gross weight |
69kgs
|
Features of CYCJET High-resolution Inkjet Printer:
Printing Effect of CYCJET High-resolution Inkjet Printer:
